VR(A)B_LD-10WR3系列
VR(A)B_LD-10WR3 系列产品输出功率为10W，2:1宽电压输入范围，效率高达86%，1500VDC的常规隔离电压，允许工作温度-40?Cto+85?C，具有输出过流、短路保护功能，广泛应用于医疗、工控、电力、仪器仪表、通信、铁路等领域。
Product Features:
宽范围输入(2:1),输出 10W 转换效率 86%6(TyP) 隔离电压 1500Vdc 待机功耗:0.3W(典型值)超快速启动:100ms(典型值)工作温度范围:-40°C~+85°C输出短路，过流保护金属外壳，输出纹波低国际标准引脚，PCB板直插安装
| Model Title | Power (W) |
Input Voltage (VAC) |
Input Voltage (VDC) |
Output Voltage (VDC) |
Output Current (mA) |
Isolation Voltage (mA) |
Packaging Form | Package size (mm) |
Data Download (3D/PCB封装库/ Schematic Diagram Library) |
Certification/Standard | Technology Manual |
Sample Apply |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
VRB1203LD-10WR3
|
10 | 9.0000-18.0000 | 3.3 | 50.8*25.4*11.0 |
|
|
 |
|||||
|
VRB1205LD-10WR3
|
10 | 9.0000-18.0000 | 5 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRB1212LD-10WR3
|
10 | 9.0000-18.0000 | 12 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRB1215LD-10WR3
|
10 | 9.0000-18.0000 | 15 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRB1224LD-10WR3
|
10 | 9.0000-18.0000 | 24 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRA1205LD-10WR3
|
10 | 9.0000-18.0000 | 5 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRA1125LD-10WR3
|
10 | 9.0000-18.0000 | 12 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRA1215LD-10WR3
|
10 | 9.0000-18.0000 | 15 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRA1224LD-10WR3
|
10 | 9.0000-18.0000 | 24 | 50.8*25.4*11.0 |
|
|
|
|||||
|
VRB2403LD-10WR3
|
10 | 18.0000-36.0000 | 3.3 | 50.8*25.4*11.0 |
|
|
|
